Loading Receiver and Power Board
Firmware
Receiver and power board firmware is released as a compressed file to
download and decompress. This file contains the following three files:
• ramimage.ldr – the Receiver board RAM file
• main.ldp – the Receiver board Flash file
• powbrd.ldr – the Power board RAM file
1. In FLoader, click the Device tab and set the Device Type as
“Receiver.” Click Get from Device for device information
(Figure 5-19).
Figure 5-19. Set Device Type
2. Click the Program tab and set the Capture Method to “Soft
Break Capture” (recommended) (Figure 5-20 on page 5-19).
NOTICE
Load all three files when loading new firmware.
These files must come from the same firmware
package.
