Loading New Firmware
P/N 7010-0736
5-19
Figure 5-20. Program Tab Settings
3. Browse for and select the receiver board’s RAM file and Flash
file (Figure 5-20).
4. Click Load and wait until 100% of the files load into the receiver.
5. Click the Device tab, and set the Device Type as “Receiver’s
Power Board”. Then click Get from Device for device
information (Figure 5-21).
Figure 5-21. Set Device Type
If you selected an incorrect file, an error message
displays at the bottom of the dialog box. Select the
correct file.
