Receiver and File Maintenance
GR-3 Operator’s Manual
5-20
6. Click the Program tab and set the Capture Method to “Soft
Break Capture” (recommended) (Figure 5-22).
Figure 5-22. Program Tab Settings
7. Browse for and select the Power board’s RAM file (Figure 5-22).
8. Click Load and wait until 100% of the power board file loads into
the receiver.
9. Click FileExit.
10. Clear the receiver’s NVRAM (see “Clearing the NVRAM” on
page 5-13) and update the almanac (see “Collecting Almanacs
and Ephemerides” on page 2-26) after loading new firmware.
NOTICE
If you selected an incorrect file, an error message
displays at the bottom of the dialog box. Select the
correct file.
