GRS-1 Specifications
P/N 7010-0926
A-3
Waterproof IP66 at closing all connector caps.
IPX4 (Weatherproof) at connecting external antenna
cable.
Power
Internal battery Li-ion, 2500 mAh 7.4V; replaceable (BT-66Q)
Operating time No less than 3.5 hours with GPS and cell phone use
No less than 4 hours with GPS use
No less than 9 hours without GPS and cell phone use
External power 1 port
Input voltage 8 to 15 V DC (for work)
10 to 15 V DC (for charge battery)
Output 12 V - 3 A
Consumption 5.3 W (with Windows Mobile and GPS and GSM)
Battery charger Connect the AC adaptor to charge the power port.
Available run charge when connected to a portable
external source
Charging time within 5 hours for full charge
Charging
Temperature
0°C to 40°C
On-board Backup battery (CR2032) for timekeeping; replaceable
button-type battery; 8–10 years normal operation
Communication
Serial port Port A of GPS+ board
Baud rate = 460800, 230400, 115200, 2400, 1200, 600,
300
Flow control = RTC/CTS
Length= 7, 8 (default)
Stop bit= 1 default, 2
Parity= None (default), Odd, Even
Bluetooth Version: Bluetooth standard 1.2; Class 2; Profile: SPP,
DUP
Table A-1. GRS-1 General Specifications (Continued)
