GRS-1 Specifications
P/N 7010-0926
A-7
Bluetooth Details
Table A-3 lists the GPS board’s general specifications.
Kinematic, RTK
For L1/L1 +L2 – H: 10mm + 1.0ppm (x baseline length)
;
V: 15mm + 1.0ppm (x baseline length)
DGPS Post processing/RTCM: typically less than 0.5m (RMS)
Other (GPS)
Real time data
format
RTCM 2.3, 3.0; CMR, CMR+; TPS
NMEA NMEA 2.2, 2.3, 3.0
Output rate Up to 10 Hz
Table A-3. Bluetooth Specifications
Transmission
Version Bluetooth® 1.2
Method Frequency hopping spread spectrum (FH-SS)
communication
Distance
5m (in good visibility)
a
a. Transmission distance will be affected by environmental factors. Radio
wave distance may be narrowed near reinforced concrete buildings and
large metallic furniture.
Speed 1 Mbps (max.)
Other (Bluetooth)
Modulation Method GFSK
Antenna Internal Chip Antenna
Frequency Range 2.4 GHz (2,402 - 2,480 MHz) (0-78 ch)
Corresponding
Profile
SPP, DUN
Table A-2. GPS Board Specifications (Continued)
