Topcon GRS-1 - GNSS Compass and Camera Usage; Topcon Receiver Utility (TRU)

P/N 7010-0926
Chapter 4
4-1
Using the GNSS
Compass, Camera
Topcon Receiver Utility
Topcon Receiver Utility for GRS-1 is a simple utility that manages
the compass and receiver board settings in the GRS-1. When first
opening Topcon Receiver Utility or after a reset, all settings will be at
the default selections. Typical GNSS settings only need to be
configured once. Occasionally, individual uses may require different
settings. Topcon Receiver Utility saves logged satellite information.
Table 4-1 summarizes the screens and settings in Topcon Receiver
Utility.
Table 4-1. Topcon Receiver Utility Screens
Description Screen
Status
The Status screen displays the current
position, satellite information, sky plot,
and position in time.
