Grading a City Street
P/N 7010-0344
5-33
Next use the sidewalk grade as a reference to cut the curb grade. Dial
in the desired grade and slope.
Figure 5-48.
For best results, stay about 6 inches in from the paint marks on the
“rough in” passes to avoid material spilling onto the sidewalk grade.
Figure 5-49.
0.75
F
T
CONTROL MODE
G A INS E T/ + / — /M E NU
-
6.0%
T R IM
LEFT SONIC
STRINGLINE
6.0%
SLOPE
3.5'
VIEW FROM BEHIND GRADER
C
L
6 "
"ROUGH IN" PASS
FINISH PASS
