Grading a City Street
P/N 7010-0344
5-35
For best results, stay about 6 inches in from the paint marks on the
“rough in” passes to avoid material spilling onto the curb grade.
Continue to grade the street across the centerline. Grade the opposite
sidewalk curb, and street section and the project is complete.
Figure 5-52.
SONIC
STRINGLINE
2.0%
SLOPE
SONIC
STRINGLINE
SONIC
STRINGLINE
SONIC
STRINGLINE
2.0%
SLOPE
SONIC
STRINGLINE
SONIC
STRINGLINE
2.0%
SLOPE
C
L
C
L
C
L
