Grading Applications
Motorgrader System Five Operator’s Manual
5-42
Use Sonic Tracker and Cross Slope to cut grade from the opposite
curb.
Figure 5-65.
Use Sonic Tracker and Sonic Tracker to match grade and finish the
street.
Figure 5-66.
Method 2
For this method, blue tops will need to be set at the centerline of the
street.
Using Sonic Tracker and Cross Slope, cut grade from one curb.
Figure 5-67.
C
L
2.0%
C
L
C
L
2.0%
