Grading From Curbs Placed at Different Elevations
P/N 7010-0344
5-43
Manually cut centerline grade from the blue tops, and use cross slope
on the trailing edge leaving the windrow on this side of the street.
Figure 5-68.
Use Sonic Tracker and Cross Slope to match the centerline grade.
Figure 5-69.
Use Sonic Tracker and Cross Slope to cut grade from the opposite
curb.
Figure 5-70.
2.0%
MANUAL
OPERATION
C
L
2.0%
C
L
2.0%
