Control Box
P/N 7010-0344
2-11
• Set (Elevation Control Only)
Pressing the Set button will allow the operator to set the elevation
grade reference number to any value desired. This does not
change the elevation, it only changes the reference number
displayed on the Control Box. (Refer to Setting Reference
Number section within this manual).
Figure 2-16.
