Control Box
P/N 7010-0344
2-17
• Calibration
Why do you need to calibrate?
Although System Five does not usually require maintenance or
adjustment, the grader it is attached to does. All the moving parts
on your grader wear at different rates. In order for System Five to
work correctly, it has to be "told" what changes have occurred on
your grader. (To perform Calibration Settings refer to the
Calibration Chapter in this manual).
• Set Points
Allows operator to decide how many sets of preset values will be
stored in the box—1, 2, or 3. (See Set Points Section of Manual).
Figure 2-22.
• Measurement Unit
1. Using the right hand knob either select "FEET" or
"METERS".
2. Press the "ENTER" button.
Figure 2-23.
SET POINTS
E
NT
E
R
E
XIT
Enter number of
set points desired
2
MEASURE UNIT
E
NT
E
R
E
XIT
FEET
METER
