Grading Applications
Motorgrader System Five Operator’s Manual
5-4
2. Using an anchor pin at each end, roll out the Sonic Stringline the
length of the working area and pull the stringline tight.
3. After the stringline has been pulled tight, place it into the
“fingers” of each Sonic Grade Clip.
Figure 5-3.
4. Decide what the Sonic Stringline hike-up (the distance from
Finished Grade to the Sonic Stringline) should be: in this case, 2
feet.
Make a cut/fill lath using a lath and a Topcon Cut/Fill Decal.
