Toradex Verdin - Verdin Top Side Signal Definitions (CSI, UART, USB, RGMII, Ethernet, PCIe)

Verdin Carrier Board Design Guide
Preliminary – Subject to Change
Toradex AG l Ebenaustrasse 10 l 6048 Horw l Switzerland l +41 41 500 48 00 l www.toradex.com l info@toradex.com
Page | 100
83
GND
85
HDMI_1_TXD2_N
Differential Pair Output
"Reserved"
87
HDMI_1_TXD2_P
Differential Pair Output
"Reserved"
89
CSI
GND
91
CSI_1_MCLK
Output 1.8V
"Reserved"
93
I2C_4_CSI_SDA
Open Drain 1.8V
"Reserved"
95
I2C_4_CSI_SCL
Open Drain 1.8V
"Reserved"
97
GND
99
CSI_1_D3_P
Differential Pair Input
"Reserved"
101
CSI_1_D3_N
Differential Pair Input
"Reserved"
103
GND
105
CSI_1_D2_P
Differential Pair Input
"Reserved"
107
CSI_1_D2_N
Differential Pair Input
"Reserved"
109
GND
111
CSI_1_CLK_P
Differential Pair Input
"Reserved"
113
CSI_1_CLK_N
Differential Pair Input
"Reserved"
115
GND
117
CSI_1_D1_P
Differential Pair Input
"Reserved"
119
CSI_1_D1_N
Differential Pair Input
"Reserved"
121
GND
123
CSI_1_D0_P
Differential Pair Bidirectional
"Reserved"
125
CSI_1_D0_N
Differential Pair Bidirectional
"Reserved"
127
GND
129
UART
UART_1_RXD
Input 1.8V
"Always Compatible"
131
UART_1_TXD
Output 1.8V
"Always Compatible"
133
UART_1_RTS
Output 1.8V
"Reserved"
135
UART_1_CTS
Input 1.8V
"Reserved"
137
UART_2_RXD
Input 1.8V
"Always Compatible"
139
UART_2_TXD
Output 1.8V
"Always Compatible"
141
UART_2_RTS
Output 1.8V
"Reserved"
143
UART_2_CTS
Input 1.8V
"Reserved"
Notch
145
DEBUG UART
GND
147
UART_3_RXD
Input 1.8V
"Always Compatible"
149
UART_3_TXD
Output 1.8V
"Always Compatible"
151
UART_4_RXD
Input 1.8V
"Reserved"
153
UART_4_TXD
Output 1.8V
"Reserved"
155
USB
USB_1_EN
Output 1.8V
"Always Compatible"
157
USB_1_OC#
Input 1.8V
"Always Compatible"
159
USB_1_VBUS
Input 5V Tolerant
"Always Compatible"
161
USB_1_ID
Input 1.8V
"Always Compatible"
163
USB_1_D_N
Differential Pair Bidirectional
"Always Compatible"
165
USB_1_D_P
Differential Pair Bidirectional
"Always Compatible"
167
GND
