Figure 92: Carrier Board Land Pattern (mm)
4.6 Carrier Board Space Requirements
The required PCB area for the module depends on the module fixing method and the cooling
solution.
0.30
Ø3.00
Ø1.60
Ø1.10
68.80
1.025
1.275
1.025
1.275
31
.00
1.80
35.50 28.50
2.50
0.50
35.50 28.50
2.50
1
.75
5.60
3.50
4
.60
4
.10
4
.10
12
.00
0.60
Ø5.30
18
.00
3.50
No Components allowed
on Carrier Board
with 5.2mm Connector
