Page | 105
170
GND
172
MSP_36
Differential Pair/ Single Ended
"Module-specific"
174
MSP_37
Differential Pair/ Single Ended
"Module-specific"
176
MSP_38
GND/ Low Speed/ Single Ended
"Module-specific"
178
MSP_39
Differential Pair/ Single Ended
"Module-specific"
180
MSP_40
Differential Pair/ Single Ended
"Module-specific"
182
GND
184
MSP_41
Differential Pair/ Single Ended
"Module-specific"
186
MSP_42
Differential Pair/ Single Ended
"Module-specific"
188
MSP_43
GND/ Low Speed/ Single Ended
"Module-specific"
190
MSP_44
Differential Pair/ Single Ended
"Module-specific"
192
MSP_45
Differential Pair/ Single Ended
"Module-specific"
194
SPI
GND
196
SPI_1_CLK
Output 1.8V
"Always Compatible"
198
SPI_1_MISO
Input 1.8V
"Always Compatible"
200
SPI_1_MOSI
Output 1.8V
"Always Compatible"
202
SPI_1_CS
Output 1.8V
"Always Compatible"
204
GPIO
GND
206
GPIO_1
Bidirectional 1.8V
"Always Compatible"
208
GPIO_2
Bidirectional 1.8V
"Always Compatible"
210
GPIO_3
Bidirectional 1.8V
"Always Compatible"
212
GPIO_4
Bidirectional 1.8V
"Always Compatible"
214
PWR_1V8_MOCI
1.8V Output 250mA max.
"Always Compatible"
216
GPIO_5_CSI
Bidirectional 1.8V
"Always Compatible"
218
GPIO_6_CSI
Bidirectional 1.8V
"Always Compatible"
220
GPIO_7_CSI
Bidirectional 1.8V
"Always Compatible"
222
GPIO_8_CSI
Bidirectional 1.8V
"Always Compatible"
224
PCIe
GND
226
PCIE_1_CLK_N
Differential Pair Output
"Reserved"
228
PCIE_1_CLK_P
Differential Pair Output
"Reserved"
230
GND
232
PCIE_1_L0_RX_N
Differential Pair Input
"Reserved"
234
PCIE_1_L0_RX_P
Differential Pair Input
"Reserved"
236
GND
238
PCIE_1_L0_TX_N
Differential Pair Output
"Reserved"
240
PCIE_1_L0_TX_P
Differential Pair Output
"Reserved"
242
GND
244
PCIE_1_RESET#
Output 1.8V
"Reserved"
246
System Control
CTRL_RECOVERY_MICO#
Open Drain Input 1.8V
"Always Compatible"
248
CTRL_PWR_BTN_MICO#
Open Drain Input 1.8V
"Always Compatible"
250
CTRL_FORCE_OFF_MOCI#
Open Drain Output, 5V Tolerant
"Always Compatible"
252
CTRL_WAKE1_MICO#
Input 1.8V
"Always Compatible"
254
CTRL_PWR_EN_MOCI
Output 1.8V
"Always Compatible"
256
CTRL_SLEEP_MOCI#
Output 1.8V
"Always Compatible"
