GND
83
84
SD_1_CD#
HDMI_1_TXD2_N
85
86
GND
"Module-specific"
HDMI_1_TXD2_P
87
88
MSP_1
CSI
GND
89
90
MSP_2
CSI_1_MCLK
91
92
MSP_3
I2C_4_CSI_SDA
93
94
MSP_4
I2C_4_CSI_SCL
95
96
MSP_5
GND
97
98
GND
CSI_1_D3_P
99
100
MSP_6
CSI_1_D3_N
101
102
MSP_7
GND
103
104
MSP_8
CSI_1_D2_P
105
106
MSP_9
CSI_1_D2_N
107
108
MSP_10
GND
109
110
GND
CSI_1_CLK_P
111
112
MSP_11
CSI_1_CLK_N
113
114
MSP_12
GND
115
116
MSP_13
CSI_1_D1_P
117
118
MSP_14
CSI_1_D1_N
119
120
MSP_15
GND
121
122
GND
CSI_1_D0_P
123
124
MSP_16
CSI_1_D0_N
125
126
MSP_17
GND
127
128
MSP_18
UART
UART_1_RXD
129
130
MSP_19
UART_1_TXD
131
132
MSP_20
UART_1_RTS
133
134
GND
UART_1_CTS
135
136
MSP_21
UART_2_RXD
137
138
MSP_22
UART_2_TXD
139
140
MSP_23
UART_2_RTS
141
142
MSP_24
UART_2_CTS
143
144
MSP_25
Notch
DEBUG UART
GND
145
146
GND
"Module-specific"
UART_3_RXD
147
148
MSP_26
UART_3_TXD
149
150
MSP_27
UART_4_RXD
151
152
MSP_28
UART_4_TXD
153
154
MSP_29
USB
USB_1_EN
155
156
MSP_30
USB_1_OC#
157
158
GND
USB_1_VBUS
159
160
MSP_31
USB_1_ID
161
162
MSP_32
USB_1_D_N
163
164
MSP_33
USB_1_D_P
165
166
MSP_34
GND
167
168
MSP_35
