4. After leveling the scale, you may plug the AC adaptor to the AC adaptor socket located in the rear of the scale.
5. When the AC adaptor is plugged into the wall outlet, the scale will automatically turn on, and go through its
initialization process.
6. To put the scale into standby mode, leave the AC adaptor plugged into both the scale and
the wall outlet and press the Power “OFF” button. The “OFF” indicator will light up in the
upper left corner of the display signaling the scale is in standby mode.
1 – pan
2 – pan support (under pan)
3 – draft ring
4 – display LCD
5 – keys
6 – rotating legs
7 – level indicator
8 – draft shield (option)
9 – draft shield cover (option)
