6
TORBAL AD series scales can operate in nine different units of measure: grams (g), kilograms (kg), carats (ct), pounds
(lb), Newton (N), grains (gn), ounces (oz), ounces troy (oz-t), and pennyweights (dwt).
By factory default the scale is set to weigh in grams (g). To select a different unit, follow the steps below.
1. Press the “M” key. Select “” by pressing the “T” key.
7
2. The scale will display available units of measure sequentially. When the desired unit is displayed, press the “T” (Yes)
key to make the selection.
Example (Selecting Kilograms):
Example (Selecting Ounces):
Note: When grams (g), kilograms (kg), carats (ct), pounds (lb), or Newton (N) are selected, the symbol for that unit will
appear to the right of the display. When a unit of measure other than the aforementioned is selected, an indicator will
appear in the bottom-left corner of the display.
3. To exit the Main Menu, use the “C” key.
