Toro ProLine H800 Service Manual

BeaconLightSwitch
g294707
Figure117
1.Beaconlightswitch
Thebeaconlightswitchislocatedonthedashpanel(Figure117).
Thebeaconlightswitchcontrolstheoperationofthebeaconlight.
TestingtheBeaconLightSwitch
g294694
Figure118
1.Parkthemachineonalevelsurface,lowerthecuttingdeck,settheparking
brake,andshutofftheengine.
2.Disconnectthebatterynegative(-)cableatthebattery.
3.Removethedashpanelandgetaccesstorearofthebeaconlightswitch;
refertoDisassemblingtheBodyAssembly(page7–6).
4.Disconnectthewireharnessconnectorfromthebeaconlightswitchand
removethebeaconlightswitchfromthedashpanel.
ElectricalSystem:TestingtheElectricalComponents
Page6–20
ProLineH800
19241SLRevB
