Toro ProLine H800 Service Manual

RearWheelMotors
g293711
Figure79
1.Bolt5.Washer9.Washer
2.Hydraulicmotor6.Nut10.Bolt
3.Spindle
7.Flange
11.Spindle
4.Woodruffkey
8.Nut
RemovingtheRearWheelMotor
CAUTION
Beforeopeningthehydraulicsystem,operateallthehydraulic
controlstoreleasesystempressureandavoidinjuryfromthe
pressurizedhydraulicuid;refertoReleasingPressurefromthe
HydraulicSystem(page5–5).
1.Parkthemachineonalevelsurface,lowerthecuttingdeck,shutoffthe
engine,settheparkingbrake,andremovethekeyfromthekeyswitch.
2.Blockthefrontwheelswithchockstopreventthemachinefrommoving.
3.Loosen,butdonotremovethelocknut(item8inFigure79)thatsecures
thewheelhubtothewheelmotor.
4.ReadtheGeneralPrecautionsforRemovingandInstallingtheHydraulic
SystemComponents(page5–63).
IMPORTANT
Beforeliftingthemachinewithajack,reviewandfollowJacking
Instructions(page1–7).
5.Liftthemachinewithajacktoremovetherearwheel,supportthemachine
withjackstands.
HydraulicSystem:ServiceandRepairs
Page5–96
ProLineH800
19241SLRevB
