Toro ProLine H800 - Height Of Cut Switch

HeightOfCutSwitch
g294710
Figure121
1.Heightofcutswitch
Theheightofcutswitchisusedtoadjustthemowerdeckcuttingheight.The
switchislocatedontheleftconsole.
Theenginemustberunningtoallowtheheightofcuttoberaisedorlowered.
Theheightofcutswitchcontrolsthesolenoidvalvecoilsontheheightofcut
controlvalve.
TestingtheHeightOfCutSwitch
1.Parkthemachineonalevelsurface,lowerthecuttingdeck,settheparking
brake,andshutofftheengine.
2.EnsurethatthekeyswitchisintheOFFpositionandthekeyisremoved
fromthekeyswitch.
3.Removetheleftarmcontrolpanelandgetaccesstorearoftheswitch;refer
toDisassemblingtheBodyAssembly(page7–6).
4.Disconnectthewireharnessconnectorfromtheheightofcutswitch.
g223017
Figure122
ElectricalSystem:TestingtheElectricalComponents
Page6–24
ProLineH800
19241SLRevB
