Toshiba B-EP Series - 5.13 Mode Setting

CHAPTER 2 OUTLINE OF SPECIFICATIONS
B-EP Series
2-2
2.2 DIMENSION
B-EP2DL 88.0 (W) x 119.0 (L) x 65.0 (D)
B-EP4DL 150.0 (W) x 145.0 (L) x 75.0 (D)
* Excluding the projecting parts.
2.3 WEIGHT
B-EP2DL
B-EP2DL-GH20-QM-R Approx. 475 g
B-EP2DL-GH30-QM-R Approx. 480 g
B-EP2DL-GH40-QM-R Approx. 480 g
B-EP2DL-GH32-QM-R Approx. 480 g
B-EP4DL
B-EP4DL-GH20-QM-R Approx. 855 g
B-EP4DL-GH30-QM-R Approx. 860 g
B-EP4DL-GH40-QM-R Approx. 865 g
B-EP4DL-GH32-QM-R Approx. 860 g
* Including a battery, excluding paper
2.4 PRINTING METHOD
Direct thermal
2.5 HEAD SPECIFICATION
B-EP2DL 8 dots/mm
B-EP4DL 8 dots/mm
2.6 PRINT SPEED
Approx. 12.5 mm/sec to Approx. 105 mm/sec
(at 25°C when using the battery designated and paper recommended by Toshiba TEC)
2.7 PRINT MODE
• LABEL mode
• RECEIPT mode
• TPCL mode
• ESC/POS mode
* ESC/POS
TM
is a registered trademark of Seiko Epson Corporation.
