CHAPTER 7 RECEIPT MODE (INTERFACE COMMANDS)
B-EP Series
7-57
7.13 EXAMPLES
7.13.1 EXAMPLES OF USING COMMANDS
[Examples of transmitted data]
Command/Print data Result
1) [ESC] 3 [20H] Setting the length of a line feed (32 dots)
ABC [LF] Printing characters and a line feed
2) [ESC] a1ABC [LF] Alignment of the print position (Center) + Printing and a line feed
3) [ESC] a0ABC Alignment of the print position (Left)
[ESC] a2DEF [LF] Alignment of the print position (Right) + Printing and a line feed
4) [LF] Line feed
5) [ESC] a0 Alignment of the print position (Left)
AB Printing characters (1x1 magnification)
[ESC] ! [10H] AB Printing characters (1x2 magnification)
[ESC] ! [20H] AB Printing characters (2x1 magnification)
[ESC] ! [30H] AB
[LF]
Printing characters (2x2 magnification)
Printing and a line feed
Paper feed direction
Effective print width (Width of head)
A
B C
1) Setting the length of a line feed and printing
characters
Width of receipt
A
B C
A
B C D E F
A
B AB
* 5 4 3 2 1
G H I J K
Graphic
4 9 4 0 0 4 5 8
2) Aligning characters at the center
3) Aligning characters on the left and the right
4) Line feed only
5) Including characters which have different
magnifications together.
6) Printing a barcode
7) Including graphics and characters together.
8) Printing a barcode (Aligning at the center)
