CHAPTER 7 RECEIPT MODE (INTERFACE COMMANDS)
B-EP Series
7-19
7.5.6 BARCODE HORIZONTAL SIZE COMMAND [GS] w
Function Sets the horizontal size of the barcode. For QR code, the 1-cell width is set.
Format [GS] wn
Term n: Horizontal size of the barcode (1 byte)
02H to 05H
Initial value n: 02H
Explanation (1) When “n” is set to any value other than the above, a command error occurs.
(2) The horizontal size designated by this command is as follows.
1 dot = 1/8 mm on the 203-dpi printer.
The maximum value varies depending on model and barcode type.
Model B-EP2DL-GHxx B-EP2DL-GHxx
Range 02H to 05H 02H to 0AH
Initial value 02H 02H
JAN-system *1 Max. value 03H 06H
NW7-system *2 Max. value 05H 0AH
PDF417 Max. value 03H 06H
QR code Max. value 05H 0AH

*1 The JAN system refers to JAN8, EAN8, EAN8 + 2 digits, EAN8 + 5 digits,
JAN13, EAN13, EAN13 + 2 digits, EAN13 + 5 digits, EAN128, UCC/EAN128,
CODE128, UPC-E, UPC-E + 2 digits, UPC-E + 5 digits, UPC-A, UPC-A + 2
digits, UPC-A + 5 digits and CODE93.
*2 The NW7 system refers to NW7, CODE39, Interleaved 2 of 5 and MSI.
[JAN8, EAN8, EAN8 + 2 digits, EAN8 + 5 digits, JAN13, EAN13, EAN13 + 2 digits,
EAN13 + 5 digits, EAN128, UCC/EAN128, CODE128, UPC-E, UPC-E + 2 digits,
UPC-E + 5 digits, UPC-A, UPC-A + 2 digits, UPC-A + 5 digits, CODE93]
n
1 module 2 modules 3 modules 4 modules
Bar Space Bar Space Bar Space Bar Space
02H 2 4 6 8
03H 3 6 9 12
04H 4 8 12 16
05H 5 10 15 20
06H 6 12 18 24
07H 7 14 21 28
08H 8 16 24 32
09H 9 18 27 36
(Unit: dots)
