SELF-DIAGNOSIS MODES

5 - 1

5. SELF-DIAGNOSIS MODES

5.1 Overview

[A] Starting each mode

To enter the desired mode, turn the power ON while pressing two digital keys designated to each mode

(e.g. [0] and [5]) simultaneously. Press the 2 key until the text in the “Display” line of the following table

appears.

On the authentication screen displayed after starting up each mode, enter the service password, and

then press [OK]. The password is not set by default.

[B] Exiting from each mode

Turn off the main switch to exit the self diagnosis mode.

[C] List of modes

Mode For start Contents For exit Display

Model

20L/

23L/

25L

20H/

23H/

25H

23LA/

23LM/

28LM

23HA/

28HA

Control

panel

check

mode

[0] + [1] +

[POWER]

All LEDs on the

control panel are

lit, and all the

LCD pixels blink.

[POWER]

OFF/ON

All the LCD pixels

blink.

YY Y Y

Test mode [0] + [3] +

[POWER]

Checks the

status of input/

output signals.

[POWER]

OFF/ON

TEST_MODE_C

MC=

YY Y Y

Te s t p r i n t

mode

[0] + [4] +

[POWER]

Outputs the test

patterns.

[POWER]

OFF/ON

TEST_MODE_P

ENTER THE CODE

DRAWER

PAPER TYPE

YY Y Y

Adjustment

mode

[0] + [5] +

[POWER]

Adjusts various

items.

[POWER]

OFF/ON

TEST_MODE_A

MC=

YY Y Y

Setting

mode

[0] + [8] +

[POWER]

Sets various

items.

[POWER]

OFF/ON

TEST_MODE_D

MC=

YY Y Y

Assist

mode

[3] +

[CLEAR] +

[POWER]

When replacing

the MAIN circuit

board, the

assistance mode

can be used to

configure

memory clear

and memory

safe delete.

[POWER]

OFF/ON

FIWMWARE ASSIST

MODE

CLEAR SRAM

ERASE SRAM

SECURELY

YY Y Y

List print

mode

[9] +

[START] +

[POWER]

Prints various

lists.

[POWER]

OFF/ON

TEST_MODE_L

ENTER THE CODE

DRAWER

YY Y Y

PM support

mode

[6] +

[ST

ART] +

[POWER]

Clears each

counter.

[POWER]

OFF/ON

PM SUPPORT MODE

ENTER THE CODE

YY Y Y

Flash

memory

clear mode

[6] +

[CLEAR] +

[POWER]

Mode for

clearing the

Flash memory

and setting the

MFP Serial No.

[POWER]

OFF/ON

SRAM CLEAR MODE

SET SERIAL

NUMBER

CLEAR SRAM

ENGINE SPEED INIT.

YY Y Y

Flash

memory

backup/

restore

mode

[5] + [9] +

[POWER]

Backup and

restore the flash

memory data to

USB device.

[POWER]

OFF/ON

SRAM COPY MODE

BACKUP SRAM

DATA

RESTORE SRAM

DATA

YY Y Y
