© 2005 - 2008 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO281c/351c/451c
TROUBLESHOOTING
5 - 121
5
7) Blurred image
Fig. 5-7
Toner offset (Shadow image appears approx. 173 mm behind the high density image.)
Cause/Section Step Check items Measures
Scanner 1 Is the scanner bedewed? Clean it.
Drum 2 Is the drum bedewed or dirty? Wipe the drum with dry cloth.
* Be sure never use alcohol or other
organic solvents because they have
bad effect on the drum.
Ozone exhaust 3 Is the ozone exhaust fan operating prop-
erly?
Check the connection of the connector.
4 Is the ozone filter stained or damaged? Replace it.
Feeding direction
To Next Page
