FIRMWARE UPDATING
6 - 2
6.1 Firmware Updating with Download Jig
In this equipment, it is feasible to update the firmware automatically by connecting the download jig
using the dedicated connector and turning ON the equipment.
The download jig consists of the ROM, in which the program is written, and the jig board.
Two types of the download jigs are available for each type of the firmware.
For updating the firmware, in addition to the current ways such as updating each firmware individually,
the batch update of the firmware of the equipment is available (except the hard disk and the option).
Refer to the following for the details to update with each download jig.
P. 6-4 "6.1.1 PWA-DWNLD-350-JIG2 (48 MB)"
P. 6-20 "6.1.3 K-PWA-DLM-320"
Firmware Stored
Download jig
Batch update Individual update
System ROM System control PC board
(SYS board)
* The system firmware is
stored into the hard disk
from the FROM basic sec-
tion software version
“V1.01/2.30”.
PWA-DWNLD-350-JIG2
(48 MB)
<Two download jigs are
needed.>
-
Engine ROM Logic PC board
(LGC board)
K-PWA-DLM-320
Scanner ROM Scanning section control PC
board
(SLG board)
K-PWA-DLM-320
RADF ROM RADF control PC board
(MR-3018)
- K-PWA-DLM-320
Finisher ROM
(Finisher firmware)
Finisher control PC board
(MJ-1101/MJ-1023/MJ-1024)
- K-PWA-DLM-320
Finisher ROM
(Saddle stitcher firmware)
Finisher control PC board
(MJ-1024)
- K-PWA-DLM-320
Hole punch unit ROM
(Hole punch unit firmware)
Hole punch control PC board
(MJ-6101)
- K-PWA-DLM-320
FAX ROM FAX board (GD-1200) - K-PWA-DLM-320
