Enter a desired value to the command line, using alphanumeric keys, → key,
and ← key. Then the following display appears.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 5 5 5 5 5 = 3 0 0 , 300 , 3 00 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
3 3 3 _ w / . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
Keys operative in the command line input mode and their operations are
shown below.
Key Descriptions
←
Used to move the cursor left on the command line.
→
Used to move the cursor right on the command line.
Numeral
. + –
Used to input characters on the command line.
EXE
Used to change current position element to an entered one.
The system returns to the position directory display mode with
the main cursor moved to the next data column.
INS
Used to select the insert or replace mode for the command
line.
BS
Used to delete one (1) character just before the cursor position
on the command line.
ALT +BS
Used to delete one (1) character at the cursor position on the
command line.
ESC
This function works in a different manner according to the
presence or absence of input character(s).
Presence of input character(s): All input character(s) on the
command line are cleared.
Absence of input character(s): The system returns to the
positional data directory display.
STE 80720
– 5-11 –
