OPERATOR’S MANUAL
series Robot Controller
Press the EXE key, and the position element is replaced by the newly
specified data. The system returns to the positional data directory display
mode with the main cursor moved to the next data column. The following
display appears.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 5 5 5 5 5 =333, 3 0 0 , 3 0 0 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
3 0 0 _ w / . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
• The main cursor moves to the next data column. When you have edited the
CONFIG data, however, the cursor will not move.
• If the input data is illegal, a message saying "ILLEGAL DATA" is displayed on
the command line and no data is changed. Press any key, and the system
returns to the element editing mode.
(3) Caution
When the CONFIG data is edited, only the first character of the data can be
edited.
The relationship between the input character and the set value is shown below.
Input character Set value
F or 0 FREE
R or 1 RIGHT
L or 2 LEFTY
STE 80720
– 5-12 –
