OPERATOR’S MANUAL
series Robot Controller
Keys operative in this mode and their operations are shown below.
Key Descriptions
↑
Used to widen the selection range upward.
↓
Used to widen the selection range downward.
ALT + ↑
Used to widen the selection range upward on the screen
basis.
ALT + ↓
Used to widen the selection range downward on the screen
basis.
ESC
Cancels the range selection and returns the system to the
positional data directory display mode.
Operation of the command menu is shown below.
Menu Descriptions
[CUT] Used to save the data in the selection range in the cut buffer and
delete that data.
(b) Step 2: Cut.
Move the main cursor by means of the ↓ key to change the selection range.
The following display then appears.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 0 0 0 0 5 = 3 0 0 , 3 0 0 , 3 0 0 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
P O I N T 0 0 0 0 5 w / . w o r l d
C U T
STE 80720
– 5-32 –
