TX-VG1530
N300 Wireless VoIP GPON Router User Guide
 USB: The USB port connects to a USB storage device or a USB printer.
 LAN1, LAN2, LAN3, LAN4: Through these ports, you can connect the Router to your PC or
the other Ethernet network devices.
 WiFi: The switch for the WiFi function.
 RESET: There are two ways to reset the Router's factory defaults.
Method one: With the Router powered on, use a pin to press and hold the Reset button for at
least 6 seconds. And the Router will reboot to its factory default settings.
Method two: Restore the default setting from “Maintenance-SysRestart” of the Router's
Web-based Utility.
 WPS: The switch for the WPS function. For details, please refer to 4.6.2 WPS Settings
.
 Optical: Through the port, you can connect the GPON router with a fiber.
 PHONE1/PHONE2: The phone port connects to a phone set.
 Antennas: Used for wireless operation and data transmit.
6
