Detection when the counting value is equal to the setting value of F5.37
±18: Reverse detection
Detection when the drive runs at reversed direction.
±19: NTC temperature warning detection (OHt)
Detection when the drive temperature sensed by thermal detector(NTC) is
higher than the temperature warning level (F4.14).
±20: Fan operation detection
±21: PTC temperature warning detection (OH1)
Detection when the motor temperature sensed by PTC detector is higher
than the PTC temperature warning level (F4.21).
【F5.30】 UP/DOWN Memory Selection
0: Erasing the frequency command setting in memory to 0.00Hz when power is
interrupted.
1: Storing the frequency command setting to function F5.30 when power is
interrupted.
【F5.31】 UP/DOWN Frequency Calibration
The calibrating range of frequency command of UP/DOWN command
Setting Value Unit The Calibrating Range of Frequency Command
0: 0.01Hz 0.01Hz
1~8: ×0.05Hz Setting 8 to calibrate frequency command.
9: 0.05Hz 0.05Hz
10~250: ×0.1Hz Setting 250 to calibrate frequency command.
【F5.32】 UP/DOWN Calibrating Time
1~5: The response time of terminal calibration (unit: second)
If UP/DOWN terminal (see F5.19~5.22 for UP/DOWN terminal setting) is set
to ON/OFF over the response time of terminal calibration, motor will continue
accelerating/decelerating to the maximum/minimum running speed
(frequency) – ON for acceleration operation and OFF for deceleration
operation.
6: Edge trigger
The trigger mode uses the input signal edge as the trigger signal without being
controlled by the trigger response time. The signal responding time is 30ms.
【F5.33】 UP/DOWN Frequency Adjustment
Frequency command is directly adjusted by keypad. The setting value of frequency
command will be stored to function F5.33 after 5 seconds when using UP/DOWN
command to set the frequency command.
UP/DOWN time chart:
76
