Trane Optimus RTHD - Rigging Dimensions (Continued); Unit Lift and Tipping Hazards

RTHD-SVX01L-EN
21
Table 5. Rigging dimensions (continued)
Unit Configuration
(a)
Units
Dimension
A B C D E F
C2F2F3
in 144.00 132.00 63.40 3.98 24.29 24.00
mm 3658 3353 1610 101 617 610
D1D1E1
in 120.00 108.00 60.00 7.36 24.09 24.00
mm 3048 2743 1524 187 612 610
D1F1F2
in 144.00 132.00 63.46 3.90 24.49 24.00
mm 3658 3353 1612 99 622 610
D1G1G1
in 144.00 132.00 63.46 3.90 25.75 24.00
mm 3658 3353 1612 99 654 610
D1G2G2
in 144.00 132.00 63.54 3.82 26.02 24.00
mm 3658 3353 1614 97 661 610
D2D2E2
in 120.00 108.00 59.96 7.40 24.17 24.00
mm 3048 2743 1523 188 614 610
D2F2F3
in 144.00 132.00 63.39 3.98 24.29 24.00
mm 3658 3353 1610 101 617 610
D2G2G1
in 144.00 132.00 63.46 3.90 25.75 24.00
mm 3658 3353 1612 99 654 610
D2G3G3
in 144.00 132.00 63.46 3.90 25.75 24.00
mm 3658 3353 1612 99 654 610
D3D2E2
in 120.00 108.00 60.00 7.40 24.17 24.00
mm 3048 2743 1523 188 614 610
D3F2F3
in 144.00 132.00 63.39 3.98 24.29 24.00
mm 3658 3353 1610 101 617 610
D3G2G1
in 144.00 132.00 63.46 3.90 25.75 24.00
mm 3658 3353 1612 99 654 610
E3D2E2
in 120.00 108.00 60.00 4.57 24.09 24.00
mm 3048 2743 1525 116 612 610
E3F2F3
in 144.00 132.00 63.46 1.14 24.21 24.00
mm 3658 3353 1612 29 615 610
E3G2G1
in 144.00 132.00 63.82 0.79 26.00 24.00
mm 3658 3353 1621 20 661 610
(a)
Designator corresponds to digits 6, 7, 14, 15, 21 and 22 of model number.
Important: Rigging dimensions given in Table 5, p. 20 are
given as a starting point reference. Lifting
cables should be adjusted as necessary for
even unit lift.
WARNING
Improper Unit Lift!
Failure to properly lift unit in a LEVEL position could
result in unit dropping and possibly crushing
operator/technician which could result in death or
serious injury, and equipment or property-only
damage.
Test lift unit approximately 24 inches (61 cm) to verify
proper center of gravity lift point. To avoid dropping of
unit, reposition lifting point if unit is not level.
WARNING
Risk of Unit Tipping!
Failure to follow below instruction could result in
death or serious injury.
Connect an anti-rotation strap between the lifting
beam and compressor before lifting unit to avoid
failure of lifting cable.
Installation Mechanical
