Installation Checklist for Model RTHB/RTHC Series R
To:______________________________________________________ Trane Service Company
S.O. No.:_________________________________________________Serial No: ___________________________
Job/Project Name:____________________________________________________________________________
RECEIVING
Verify that the unit nameplate data corresponds to the ordering information.
Inspect the unit for shipping damage and any shortages of materials. Report any damage or shortage to the carrier.
UNIT LOCATION AND MOUNTING
Inspect the location desired for installation and verify adequate service access clearances.
Provide drainage for evaporator and condenser water.
Remove and discard all shipping materials (cartons, etc.)
Install optional spring or neoprene isolators, if required. Refer to IOM for details.
Level unit and secure it to the mounting surface.
UNIT PIPING
CAUTION: If using an acidic commercial flushing solution, construct a temporary bypass around the unit to prevent damage to the internal
components of the condenser and evaporator. To avoid possible equipment damage, do not use untreated or improperly treated system water.
Flush all unit water piping before making final connections to unit.
Connect water piping to the evaporator and condenser.
Install pressure gauges and shutoff valves on the water inlet and outlet to the evap. and cond.
Install water strainers in the entering chilled water and condenser water lines.
Install balancing valves (discretionary) and flow switches in the leaving chilled and condenser water lines.
Install drains with shutoff valves or drain plugs on the evaporator and condenser.
Vent the chilled water and condenser water systems at the high points of the system piping.
Pipe relief valves outdoors in accordance to ASHRAE 15 and the IOM.
ELECTRICAL WIRING
WA R N IN G : To prevent injury or death, disconnect electrical power source before completing wiring connections on the unit.
Check for tight connections for the unit power supply wiring with the fused disconnect to the terminal block (or unit-mounted discon-
nect) in the power section of the control panel.
Check for tight 115 volt control wiring connections to the chilled water pump and condenser water pump
Check Interlock Wiring, including chilled water pump control, chilled water flow interlock, condenser water pump, condenser water
flow interlock, external auto stop. For further details refer to the IOM or the unit wiring.
CAUTION: Information on Interconnecting Wiring: Chilled Water Pump Interlock and External Auto/Stop must be adhered to or equipment
damage may occur.
