Model RTHB/RTHC Series R Checksheet and Request for Serviceman
To:______________________________________________________ Trane Service Company
S.O. No.:_________________________________________________Serial No: ___________________________
Job/Project Name:_____________________________________________________________________________
The following items are being installed and will be complete by _________________________________________
Series R Unit
Interconnecting wiring, starter to control panel
In place and piped. Do not insulate the unit or adjacent
piping. The contractor is responsible for any foreign
material left in the unit.
External Interlock (flow switches, water pump aux.
etc.)
Piping
Chilled water pump motor connected
Chilled water piping connected to: Cooling tower fan rotation checked
Series R unit (In and out different between RTHB and RTHC, refer to IOM) Condenser water pump motor connected
Air handling units
Pump (as applicable)
Pumps Power available for vacuum pump (115 VAC)
Condenser water piping connected to: All controls installed and connected
Series R unit
(refer to IOM for details) All magnetic starters installed and connected
Cooling tower
Testing
Pumps Dry nitrogen available for pressure testing
Make-up water connected to cooling tower Rfgt available for leak testing (25 lbs)
Water supply connected to filling system
Refrigerant
Systems filled Refrigerant on job site
Pumps run, air bled from system
Gauges, Thermometers and Air Vents
Remove construction strainer and replace with perma-
nent strainer.
Installed on both sides of evap
Flow Balancing Valves Installed
Installed on both sides of the condenser
Leaving chilled water
MISC
Leaving condenser water System can be operated under load conditions
Wiring
Electrician, control man and contractor’s rep. are
available to evacuate, charge and test the Series
R under serviceman’s supervision
Compressor motor starter furnished by or approved by
the Trane Company, Pueblo, CO
Owner/contractor informed on proper water treat-
ment
In accordance with your quotation and our purchase order number _______________________________________
We will therefore require your serviceman on the job by **____________________________
This is to certify that the Series R has been properly and completely installed and the applicable items listed above
have been completed.
** Advance notification is required to allow scheduling of the start-up as close to the requested date as possible.
