[37] Fire mode A signal applied will put the frequency converter into Fire Mode and all
other commands will be disregarded. See 24-0*
Fire Mode
.
[52] Run Permissive The input terminal, for which the Run permissive has been programmed
must be logic “1” before a start command can be accepted. Run permis-
sive has a logic ‘AND’ function related to the terminal which is program-
med for
START
[8],
Jog
[14] or
Freeze Output
[20], which means that in
order to start running the motor, both conditions must be fulfilled. If Run
Permissive is programmed on multiple terminals, Run permissive needs
only be logic ‘1’ on one of the terminals for the function to be carried out.
The digital output signal for Run Request (
Start
[8],
Jog
[14] or
Freeze out-
put
[20]) programmed in par. 5-3*, or par. 5-4*, will not be affected by
Run Permissive.
NOTE: If no Run Permissive signal is applied but either Run, Jog or Freeze
commands is activated, the status line in the display will show either Run
Requested, Jog Requested or Freeze Requested.
[53] Hand start A signal applied will put the frequency converter into Hand mode as if
button
Hand On
on the keypad has been pressed and a normal stop com-
mand will be overridden. If disconnecting the signal, the motor will stop.
To make any other start commands valid, another digital input must be
assign to
Auto Start
and a signal applied to this. The
Hand On
and
Auto
On
buttons on the keypad has no impact. The
Off
button on the keypad
will override
Hand Start
and
Auto Start
. Press either the
Hand On
or
Auto
On
button to make
Hand Start
and
Auto Start
active again. If no signal on
neither
Hand Start
nor
Auto Start
, the motor will stop regardless of any
normal Start command applied. If signal applied to both
Hand Start
and
Auto Start
, the function will be
Auto Start
. If pressing the
Off
button on the
keypad the motor will stop regardless of signals on
Hand Start
and
Auto
Start
.
[54] Auto start A signal applied will put the frequency converter into Auto mode as if
the keypad button
Auto On
has been pressed. See also
Hand Start
[53]
[55] DigiPot Increase Uses the input as an INCREASE signal to the Digital Potentiometer func-
tion described in parameter group 3-9*
[56] DigiPot Decrease Uses the input as a DECREASE signal to the Digital Potentiometer func-
tion described in parameter group 3-9*
[57] DigiPot Clear Uses the input to CLEAR the Digital Potentiometer reference described
in parameter group 3-9*
[60] Counter A (up) (Terminal 29 or 33 only) Input for increment counting in the SLC counter.
[61] Counter A (down) (Terminal 29 or 33 only) Input for decrement counting in the SLC counter.
[62] Reset Counter A Input for reset of counter A.
[63] Counter B (up) (Terminal 29 and 33 only) Input for increment counting in the SLC coun-
ter.
[64] Counter B (down) (Terminal 29 and 33 only) Input for decrement counting in the SLC coun-
ter.
[65] Reset Counter B Input for reset of counter B.
[66] Sleep Mode Forces frequency converter into Sleep Mode (see par. 22-4*). Reacts on
the rising edge of signal applied!
[78] Reset Preventive Mainte-
nance Word
Resets all data in par.16-96
Maintenance Word to 0.
5-10 Terminal 18 Digital Input
Option: Function:
[0] No operation
[1] Reset
Parameter Description
92 TR200 Programming Guide
To Next Page
