Chapter 5 UCM Wiring and Addressing
100 BMTW-SVN01F-EN
the last UCM in the chain to prevent any connection between the shield
and ground (see Figure 49 on page 102).
IMPORTANT
UCM ground loops will cause a malfunction.
Figure 47. Location of the Address DIP Switches on the CGA/CGW
UCM
Note:
Observe the polarity throughout communication links.
