VariTrac II Central Control Panel (CCP) Interface
BMTW-SVN01F-EN 125
Table 23. VariTrac II CCP DIP Switch Settings
UCM Address
VariTrac II CCP
S2 DIP Switch Settings
1 2 3 4 5
1 on OFF OFF OFF OFF
2 OFF on OFF OFF OFF
3 on on OFF OFF OFF
4 OFF OFF on OFF OFF
5 on OFF on OFF OFF
6 OFF on on OFF OFF
7onononOFFOFF
8 OFF OFF OFF on OFF
9 on OFF OFF on OFF
10 OFF on OFF on OFF
11 on on OFF on OFF
12 OFF OFF on on OFF
13 on OFF on on OFF
14 OFF on on on OFF
15 on on on on OFF
16 OFF OFF OFF OFF on
17 on OFF OFF OFF on
18 OFF on OFF OFF on
19 on on OFF OFF on
20 OFF OFF on OFF on
21 on OFF on OFF on
22 OFF on on OFF on
23 on on on OFF on
24 OFF OFF OFF on on
25 on OFF OFF on on
26 OFF on OFF on on
27 on on OFF on on
28 OFF OFF on on on
29 on OFF on on on
30 OFF on on on on
31 on on on on on
32 OFF OFF OFF OFF OFF
