50 RMWH-SVX001C-EN
Technical Data
Technical Specifications/
Equipment Ratings
Usage Indoor use only
Overvoltage Category II
Pollution Degree 2
AC Power
100–240 Vac, 50/60 Hz, 200 VA maximum
Supply voltage not to fluctuate more than ±10%
Operating Temperature 32°F–122°F (0°C to 50°C)
Operating Altitude Limit 9762 ft (2975 m)
Operating Humidity 0 to 95%, noncondensing
Ingress Protection IP54
Size
Height x Width x Depth =
15.6 in. x 13.6 in. x 7.6 in.
(39.6 cm x 34.5 cm x 19.3 cm)
Weight
4 point unit = 14 lb (6.4 kg)
8 point unit = 15 lb (6.8 kg)
16 point = 17 lb (7.7 kg)
Sensor Type Photoacoustic Infrared
Sample Line Tubing
1/4 in. OD x 1/8 in. ID
Polyurethane (ether based) or metal
with tubing
6 mm OD x 4 mm ID
Sample Line Length
Up to 400 ft (121 m) for optimum performance, will support up
to 1200 ft (366 m)
Gases
R11, R12, R22, R123, R134A, R401A, R404A, R407A, R407C,
R407F, R410A, R422A, R422
D, R427A, R507, R1233zd(E),
R1234yf, R1234ze, R-513A, R-514A
Measuring Range 0–1000 ppm
Sensitivity (minimum detection) 1 ppm for all listed gases
Accuracy (linearity) 0– 50 ppm ±1 ppm, 51–1000 ppm ±10% of reading
Sensor Response Time 90% of gas reading <70 sec
Relays 5 Form C, 8A 250 Vac resistive SPDT
Audible Alarm 95 ±5 dB(A) at 24 in. (61 cm) maximum
Communication Outputs
4–20 mA sourcing, 250 Ohm load; 0–10 V, 2 K Ohm minimum
load; RS485 Modbus RTU; RS-485 BACnet MS/TP
Gas Reading Accuracy
Gas Gas Concentration Gas Reading Accuracy
As factory calibrated:
R-134A, R-404A, R-410A, R-407C, R-123, R1233zd(E)
1–50 ppm
51–1000 ppm
±1 ppm
±10% of F.S.
As factory calibrated extended library:
R-11, R-12, R-1234ze, R-22, R-407F,
R-401A, R-407A, R-422A, R-422D, R-427A, R-507, R-1234yf, R513A, R-514A
1–50 ppm
51–1000 ppm
±3 ppm
±30% of reading
As calibrated after installation:
R-134A, R-404A, R-410A, R-407C, R-123, R1233zd(E), R-11, R-12, R-1234ze, R-22,
R-407F, R-401A, R-407A, R-422A, R-422D, R-427A, R-507, R-1234yf, R-513A, R-514A
1–50 ppm
51–1000 ppm
±1 ppm
±10% of F.S.
