Section Object Name Channel # Object Type Inst # Property Notes
Gases Calibration
Next Cal Time
Gases
Analog Input 90 Read In days from 1970
Zero Cal Time Analog Input 91 Read
In days from 1970
Span Cal Time #00 Analog Input 92 Read In days from 1970 – R-11
Span Cal Time #01 Analog Input 93 Read
In days from 1970 – R-12
Span Cal Time #02 Analog Input 94 Read In days from 1970 – R-22
Span Cal Time #03 Analog Input 95 Read
In days from 1970 – R-123
Span Cal Time #04 Analog Input 96 Read In days from 1970 – R-134A
Span Cal Time #05 Analog Input 97 Read
In days from 1970 – R-401A
Span Cal Time #06 Analog Input 98 Read In days from 1970 – R-404A
Span Cal Time #07 Analog Input 99 Read
In days from 1970 – R-407A
Span Cal Time #08 Analog Input 100 Read In days from 1970 – R-407C
Span Cal Time #09 Analog Input 101 Read
In days from 1970 – R-407F
Span Cal Time #10 Analog Input 102 Read In days from 1970 – R-410A
Span Cal Time #11 Analog Input 103 Read
In days from 1970 – R-422A
Span Cal Time #12 Analog Input 104 Read In days from 1970 – R-422D
Span Cal Time #13 Analog Input 105 Read
In days from 1970 – R-427A
Span Cal Time #14 Analog Input 106 Read In days from 1970 – R-507
Span Cal Time #15 Analog Input 107 Read
In days from 1970 – R-513A
Span Cal Time #16 Analog Input 108 Read In days from 1970 – R-514A
Span Cal Time #17 Analog Input 109 Read
In days from 1970 – R-1233zd(E)
Span Cal Time #18 Analog Input 110 Read In days from 1970 – R-1234yf
Span Cal Time #19 Analog Input 111 Read In days from 1970 – R-1234ze
Appendix E: BACnet Objects
64 RMWH-SVX001C-EN
RESET Button Actions
HiByte LoByte Description
0 channel# Reset channel-specific alarms, channel#1-#16 = 0..15
0 255
Reset all channel-specific alarms
1 channel# Reset channel-specific faults, channel#1-#16 = 0..15
1 255
Reset all channels-specific faults
2 255 Reset common faults
3 255 Reset all alarms and all faults
Unit Status Flags
Bit Description
0x0001 Warm up Set if warm-up time is pending
0x0002 Operating
Normal operating mode is set (after warm-up; not in calibration, fault, or alarm)
0x0004 Calibration Set if calibration is in progress
0x0008 Fault
Set if failure is reported
0x0010 Alarm Set if C/W/A level is achieved
0xFFE0 — Reserved
