Appendix B: Installation of Optional Equipment
56 RMWH-SVX001C-EN
7. Use a ¼-in. hex driver to remove the four hex nuts on
the circuit board cover.
8. Remove the circuit board cover.
9. Follow the wiring instructions supplied
with the
remote horn.
10. Insert the wires for the remote horn
into the Phoenix
connector marked “HORN” on the circuit board. Make
sure each wire is inserted into the correct connector
terminal:
a. For a normally de-energized relay, connect the
wires to the “C” and “NO”
terminals.
b. For a normally energized relay, connect the
wires to
the “C” and “NC” t
erminals.
11. Use a small flathead screwdriver to tighten the screws
on
the Phoenix connector and secure the wires.
12. Install the circuit board cover.
13. Use a 1/4-in. hex driver to install the four hex nuts on
the circuit board
cover.
14. Dis
connect the ESD wrist strap from the ESD
co
nnection
point inside the enclosure.
15. Close the enclosure.
16. Latch the two latches.
17. If applicable, attach the locking mechanism.
18. Supply electrical power to the device.
External Alarm Activation Station
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury.
Disconnect all electric power, including remote
disconnects before servicing. Follow proper lockout/
tagout procedures to ensure the power cannot be
inadvertently energized. Verify that no power is present
with a voltmeter. To prevent electrical shock, the circuit
board cover must be in place when power is on.
1. Disconnect electrical power to the device.
2. I
f applicable, remove the lockin
g mechanism.
3. Release the two latches on the left side of the device.
4. Open the enclosure
.
5. Attach the ESD wrist strap to the ESD connection point
i
nside th
e enclosure.
6. Follow the wiring instructions su
pplied with the alarm
activation station.
7. Insert the wires for the alarm activation station
into the
Phoenix connector marked “PULL” on the circuit
board. Make sure the wires are inserted correctly.
8. Use a small flathead screwdriver to tight
en the screws
on
the Phoenix connector and secure the wires.
9. Disconnect the ESD wrist strap from the ESD
connection
point inside the enclosure.
10. Close the enclosure.
11. Latch the two latches.
12. If applicable, attach
the locking mechanism.
13. S
upply electrical power to the device.
External Alarm Silencing Station
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury.
Disconnect all electric power, including remote
disconnects before servicing. Follow proper lockout/
tagout procedures to ensure the power cannot be
inadvertently energized. Verify that no power is present
with a voltmeter. To prevent electrical shock, the circuit
board cover must be in place when power is on.
1. Disconnect electrical power to the device.
2. I
f applicable, remove the locking mechanism.
3. Release th
e two latches on the left side of the
device.
4. Open the enclosure.
5. Attach the ESD wrist strap to the ESD connection point
inside the
enclosure.
6. Fo
llow the wiring instructions supplied with the alarm
silencing s
tation.
7. Insert the wires for the alarm s
ilencing stati
on to the
Phoenix connector marked “ACK” on the circuit board.
Make sure each wire is inserted into the correct
connector terminal.
8. Use a small flathead screwdriver to tighten the screws
on
the Ph
oenix connector and secure the wires.
9. Disconnect the ESD wrist strap from the
ESD connection point inside the enclosure.
10. Close the enclosure.
11. Latch the two latches.
12. If applicable, attach
the locking mechanism.
13. S
upply electrical power to the device.
