© Copyright 2018 TRENDnet. All Rights Reserved.
Spanning Tree Settings
System > Spanning Tree Settings
1. Log into your management page (see “Access the management page” on page
8).
2. Click on the System tab and click Spanning Tree Settings.
3. Review the settings and click Save to save changes.
Spanning Tree Status: Select ON or OFF to enable or disable spanning tree
feature.
Bridge Hello Time: Enter the bridge duration
Bridge Max Age: Enter the max duration
Bridge Forward Delay: Enter the delay duration
Priority: Enter the priority
4. Click on the Save button then click on the flashing Apply/Discard button
located on the top left section, and click Save & Apply to apply the settings.
Note: Your configurations are not saved and applied until you click on Apply/Discard
Changes button. The Save & Apply step saves and applies all configuration changes.
Band Steering
System > Band Steering
When 2.4GHz and both 5GHz bands are all using the same SSID and WiFi security
settings, band steering allows the AP to automatically detect if clients are 11AC capable
and automatically pushing them over to the underutilized 5GHz bands. This allows your
AP to use both bands more efficiently and making sure clients capable of the 11AC
standard for faster speeds are establish WiFi links at 11AC connectivity whenever
possible.
1. Log into your management page (see “Access the management page” on page
8).
2. Click on the System tab and click Band Steer.
3. Select enable to turn on band steering feature and click Save to save settings.
4. Click on the Save button then click on the flashing Apply/Discard button
located on the top left section, and click Save & Apply to apply the settings.
Note: Your configurations are not saved and applied until you click on Apply/Discard
Changes button. The Save & Apply step saves and applies all configuration changes.
To enable band steering, you have to setup steering SSID the same in both
2.4GHz and 5GHz
