TRENDnet TEW-826DAP User Manual

© Copyright 2018 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-826DAP
60
QoS
 WMM
 Bandwidth control per SSID or client
SSID
 Up to 8 SSIDs per wireless band (24 total)
Frequency
 2.4GHz: 2.412 – 2.472GHz
 5GHz
1
: 5.180 – 5.320GHz
 5GHz
2
: 5.500 – 5.825GHz
Wireless Channels
 2.4GHz: FCC: 1–11, ETSI: 1 – 13
 5GHz: FCC: 36, 40, 44, 48, 149, 153, 157, 161 and 165 ETSI: 36, 40, 44, 48 (52,
56, 60, 64, 100,104,108,112,116, 132,136,140)**
Modulation
 DBPSK/DQPSK/CCK for DSSS technique
 BPSK/QPSK/16-QAM/64-QAM/256-QAM for OFDM technique
Antenna Gain
 2.4GHz: 2 x 4 dBi internal
 5GHz1: 2 x 4 dBi internal
 5Ghz2: 2 x 4 dBi internal
Wireless Output Power
 802.11a: FCC: 27.76 dBm (max.) / CE: 28.4 dBm (max.) / IC: 30.18 dBm (max.)
 802.11b: FCC: 29.22 dBm (max.) / CE: 17.82 dBm (max.) / IC: 30.79 dBm (max.)
 802.11g: FCC: 28.2 dBm (max.) / CE: 18.71 dBm (max.) / IC: 30.23 dBm (max.)
 802.11n (2.4GHz): FCC: 28.56 dBm (max.) / CE: 18.79 dBm (max.) / IC: 30.41
dBm (max.)
 802.11n (5GHz): FCC: 28.74 dBm (max.) / CE: 28.74 dBm (max.) / IC: 30.37 dBm
(max.)
 802.11ac: FCC: 27.45 dBm (max.) / CE: 28.74 dBm (max.) / IC: 29.55 dBm (max.)
Receiving Sensitivity
 802.11a: -70 dBm (typical) @ 54 Mbps
 802.11b: -85 dBm (typical) @ 11 Mbps
 802.11g: -72 dBm (typical) @ 54 Mbps
 802.11n (2.4 GHz): -67 dBm (typical) @ 400 Mbps
 802.11n (5 GHz): -67 dBm (typical) @ 400 Mbps
 802.11ac: -64 dBm (typical) @ 867 Mbps
Power
 IEEE 802.3at Type 2 PoE PD Class 4
 Input: 100 - 240V AC, 50/60Hz, Output: 12V DC, 2A external power adapter
(optional)
 Max. consumption: 18.96W
Operating Temperature
 0° – 40° C (32° – 104° F)
Operating Humidity
 Max. 95% non-condensing
Certifications
 CE
 FCC
 IC
Dimensions
 214 x 214 x 36mm (8.4 x 8.4 x 1.4 in.)
Weight
 684g (1.51 lbs.)
