trendpoint ENKAPSIS - Address Matrix

Enkapsis & EnerSure Platform Installation Guide Rev07.2
49
Address Matrix
Address
4 Circuit
8 Circuit
1
1-4
1-8
2
5-8
Not Used
3
9-12
9-16
4
13-16
Not Used
5
17-20
17-24
6
21-24
Not Used
7
25-28
25-32
8
29-32
Not Used
9
33-36
33-40
10
37-40
Not Used
11
41-44
41-48
12
45-48
Not Used
13
49-52
49-56
14
53-56
Not Used
15
57-60
57-64
16
61-64
Not Used
17
65-68
65-72
18
69-72
Not Used
19
73-76
73-80
20
77-80
Not Used
21
81-84
81-88
22
85-88
Not Used
23
89-92
89-96
24
93-96
Not Used
25
97-100
97-104
26
101-104
Not Used
27
105-108
105-112
28
109-112
Not Used
29
113-116
113-120
30
117-120
Not Used
Note: 8-Circuit Bus Tap Cards are seen as two 4-Circuit Bus Tap Cards and therefore
utilize 2 addressing positions. Example, an 8-Circuit Card addressed at address 1 utilizes
both address positions 1 and 2. The next card in the system would be address 3. This setup
allows both 4 and 8-Circuit Bus Tap Cards to be used in the same system.
