11 Event Marker Input and 1PPS Output
116 5700/5800 GPS Receiver User Guide
5700 Operation
A typical printout looks like this:
UTC 93.12.21 20:21:16 56
UTC 93.12.21 20:21:17 56
UTC 93.12.21 20:21:18 56
If a and b are ??, the time is based on the receiver clock because the
receiver is not tracking satellites. The receiver clock is less accurate
than time readings extracted from satellite signals.
111.3 Enabling and configuring 1PPS output
To enable or configure the 1PPS output function, you need either GPS
Configurator or Configuration Toolbox.
In real time
You can use GPS Configurator to configure a Trimble GPS receiver
connected to your office computer. For more information, see GPS
Configurator Software, page 78, or refer to the GPS Configurator
Help.
To enable 1PPS output:
1. Connect the computer to the 5700 receiver.
2. Power on the 5700 receiver.
3. To start GPS Configurator, click , then select
Programs / Trimble / GPS Configurator / GPS Configurator.
The GPS Configurator dialog appears and the software
automatically connects to the 5700 receiver.
4. Select the Serial outputs tab.
5. Select the 1PPS (port 2 only) check box.
6. If you want ASCII time tags enabled, select the check box and
choose an output port.
