19 Cables and Connectors
172 5700/5800 GPS Receiver User Guide
5800 Operation
Table 19.1 describes the pinout functionality.
19.3 Power/Serial Data Cables
Note – Table 19.2 gives pinout information for the data-I/O cable,
(PN 18532) which is supplied with the 5800 receiver
Note – Table 19.2 assumes that the cable is attached to the connector
labeled Port 2.
Table 19.1 5800 port pinouts
Pin Pinout function
Port 1 - 7-pin Lemo Port 2 - DB-9
1 Signal ground DCD
2 - Power ground RXD
3TXD TXD
4N/C DTR
5 N/C Signal ground
6 + Power in DSR
7TRXD RTS
8N/A CTS
9 N/A Ring indicator
Table 19.2 Data-I/O cable pinouts
DB-9 Female
9 Pin
DB-9 Female
9 pin
Pin Function Pin Function
1-6 DCD5_232 4 DTR5_232
2 RX5_232 3 TX5_232
3 TX5_232 2 RX5_232
4 DTR5_232 1-6 DCD5_232

Trimble 5700 Specifications

General

Frequency	L1/L2
Power Consumption	6.0 W
Receiver Type	L1/L2 GPS receiver
Data Logging	Internal memory
Communication	Bluetooth
Operating Temperature	-40°C to +65°C
Power Supply	External
RTK Accuracy	10 mm + 1 ppm (horizontal), 15 mm + 1 ppm (vertical)
