13 Setting up the Receiver
130 5700/5800 GPS Receiver User Guide
5800 Operation
133.3
General guidelines
The following guidelines apply whenever you set up your receiver for
operation:
• When plugging in a Lemo cable, make sure that the red dots on
the receiver port and the cable connector line up. Never use
force to plug cables in, as this may damage the connector pins.
• When disconnecting a Lemo cable, grasp the cable by the
sliding collar or lanyard and pull the cable connector straight
out of the port. Do not twist the connector or pull on the cable
itself.
• To securely connect a TNC cable, align the cable connector
with the receiver receptacle, then thread the cable connector
onto the receptacle until it is snug.
• To insert the internal battery place the battery in the battery
compartment, ensuring that the contact points are in the correct
position to align with the contacts in the receiver. Slide the
battery and compartment as a unit upward into the receiver until
the battery compartment latches are locked into position.
13.4
Pole-Mounted Setup
Figure shows the pole-mounted setup for the 5800 receiver. To mount
the 5800 receiver on a range pole:
1. Thread the unit onto the range pole
2. Attach the controller bracket to the pole
3. Insert the controller into the bracket.
