32.3 Top panel
Figure 3.4 shows the top panel of the 5700 receiver. This panel
contains the three power/serial data ports and (TNC) ports for GPS
and radio antenna connections.
Figure 3.4 Top panel
1
2
GPS
RADIO
Power/serial data ports
TNC ports
123
GPS antenna Radio antenna
