4 General Operation
52 5700/5800 GPS Receiver User Guide
5700 Operation
4.5
Logging Data
You can log data to the CompactFlash card in the 5700 receiver, or
alternatively to the survey device.
45.1
Logging internally
The 5700 receiver logs GPS data internally on a CompactFlash card.
You can then use the Trimble Data Transfer utility to transfer logged
data files to your office computer. The transferred files are in Trimble
DAT (.dat) format.
C
Warning – The 5700 allows for a maximum of 512 files on the
CompactFlash card, regardless of the card’s capacity. The file names
must be in 8.3 format, otherwise files copied to the CompactFlash card
may cause data corruption or loss of data when logging.
Data is logged using the current logging settings configured in the
receiver. Data files logged internally are named automatically.
To begin internal logging, press d. The Logging/Memory LED
lights up.
To stop logging, hold down d for at least two seconds. The
Logging/Memory LED turns off.
Note – When the CompactFlash card is full, the receiver stops logging
data, and the Logging/Memory LED switches off. Existing data files
are not overwritten.
Approximate storage requirements for different logging rates are
shown in Table 4.2. The values shown are for a one-hour logging
session with six satellites visible.
Table 4.2 Storage requirements
Logging rate Memory required
10 Hz 2,588 KB
1Hz 335 KB
